Ubiquiti U7-Lite
WiFi 7 Access Point, Lite tier |
||||||
| A compact, budget-friendly WiFi 7 access point for smaller spaces, offering solid coverage and multi-gigabit-ready speeds without the cost of the enterprise-tier models. This model is supplied and supported by an experienced Elv contractor and established Elv company in Malaysia. | ||||||
|
||||||
|
||||||
|
Speak with Elite ELV about product supply, network installation, system configuration or a commercial site survey. |
Specification
The essential technical information is presented first. Detailed engineering specifications remain available in the official PDF datasheet. Elite ELV can integrate this access point into an integrated ELV network that supports a cctv security system, supported by professional security system planning and a coordinated door access control system.
Features | Details |
|---|---|
Device Type | WiFi 7 Access Point, Lite tier |
WiFi Standard | WiFi 7 (802.11be) |
Spatial Streams | 4 total (2×2 on 5 GHz and 2.4 GHz) |
Max Data Rate | 5 GHz 4.3 Gbps (BW240) / 2.4 GHz 688 Mbps (BW40) |
Antenna Gain | 5 dBi (5 GHz), 4 dBi (2.4 GHz) |
Max TX Power | 24 dBm (5 GHz), 23 dBm (2.4 GHz) |
Coverage Area | 115 sqm (1,250 sq ft) |
Max Client Count | 200+ |
Uplink | 2.5 GbE |
Power Input | PoE |
Dimensions | Diameter 171.5 x 33 mm |
Mounting | Ceiling, wall (Lite Mount included) |
Need sensor, frame rate, protocol, DORI or environmental details?
CCTV System for Commercial Properties
The camera supports common indoor and sheltered outdoor surveillance requirements across commercial and industrial environments. These deployments can form part of a wider Elv system installation.
01
Office Buildings
02
Retail Premises
Improve visibility across storefronts, counters, aisles and stock areas.
03
Warehouses
Support surveillance at loading zones, storage areas and access points.
04
Factories
Monitor selected production areas, gates and operational zones.
Product Supply with Professional CCTV Installation
Elite ELV supports commercial WiFi projects with site assessment, access point planning, configuration and testing. Wider deployments can combine Ubiquiti Malaysia solutions with professional network cabling installation for stable, scalable connectivity.
-
Site assessment and camera planning
-
Structured cabling and PoE setup
-
Testing and commissioning
-
CCTV equipment supply
-
NVR and remote viewing configuration
-
Maintenance and technical support
Share your site type, coverage requirements and project location with the Elite ELV team.
Related Products
You might also like these to build out your CCTV coverage and connect it with your wider ELV system.
Frequently Asked Questions
What is the Ubiquiti U7-Lite used for?
It is a compact, budget-friendly WiFi 7 access point suited to smaller spaces that don’t need enterprise-tier coverage or client capacity.
What is the coverage area of one access point?
Each U7-Lite covers approximately 115 sqm (1,250 sq ft).
How many devices can connect to one access point?
It supports 200+ simultaneous client connections.
How is this access point powered and mounted?
It is PoE powered and mounts to a ceiling or wall using the included Lite Mount.
What network speed does this access point support?
It supports WiFi 7 (802.11be) with up to 4.3 Gbps on the 5 GHz band, plus a 2.5 GbE uplink. You can see similar systems in action in our case study page.
Does Elite ELV supply and install this access point?
Yes. Elite ELV supports commercial network projects with site assessment, structured cabling, PoE setup, configuration, testing and after-sales support. If you are comparing options, our Ubiquiti U7-Long Range is a popular alternative worth reviewing.
